Machines for Production of Plastic Utensils 160T
| | | GS168V |
| A | B | C |
|
INJECTIONUNIT
| Screw Diameter | mm | 40 | 45 | 50 |
| Screw L/D Ratio | L/D | 22.5 | 20 | 18 |
| Shot size(Theoretical) | cm3 | 253 | 320 | 395 |
| PS) Injection Weight | g | 230 | 291 | 359 |
| PS Injection Rate | g/s | 100 | 126 | 156 |
| PS Plasticizing capacity | g/s | 13.9 | 18 | 21.6 |
| Injection Pressure | Mpa | 240 | 190 | 154 |
| Screw Speed | Rpm | 0-195 |
|
CLAMPINGUNIT
| Clamp Tonnage | KN | 1600 |
| Toggle stroke | mm | 430 |
| Space Between Tie Bars | mm | 470*470 |
| Max.Mold Height | mm | 520 |
| Min.Mold height | mm | 180 |
| Ejector stroke | mm | 140 |
| Ejector tonnage | KN | 33 |
| Ejector Number | piece | 5 |
|
OTHERS
| Max.Pump Pressure | Mpa | 17.5 |
| pump motor power | KW | 15 |
| Heater Power | KW | 9.75 |
| Machine Dimension(L*W*H) | m | 4.9*1.29*1.96 |
| Machine Weight | t | 5.3 |
| PS Hopper Capacity | Kg | 25 |
| Oil Tank Capacity | L | 350 |
Two Color Injection Molding Machine
Features of injection molding machine for making plastic bowls / plates / cups / spoons :
1) LCD computer control with big display screen
2) Hydraulic double proportional valve
3) Hard chrome plated high tensile strength steel tie bars
4) Generous space for fitting large moulds
5) Large opening stroke
6) Two position transducers to control Clamping and Injection
7) Four stages of injecting, independent velocity and pressure control
8) Hydraulic mould height adjustment device
9) Screw cold-start prevention device
10) Melt decompression control
11) Screw back pressure control
12) Multiple hydraulic ejection
13) Differential high speed clamping
14) Centralized lubrication system
15) Low pressure mould protection device
16) Mechanical safety interlock
17) Double electrical safety interlock
18) Oil return filter
19) Oil tank with inner stainless steel container
